1.Introduction

1.1. What is R2EdiViewer

R2EdiViewer is a file viewer to display EDI files.

The following INVRPT EDIFACT file...

...is processed by R2EdiViewer with syntax-highlighting:



For each field R2EdiViewer displays the following information:

  1. Field name
  2. Field description
  3. Field length
  4. Field content from EDI file
  5. Field explanation text {in curly brackets}
  6. Interest records / segments, but also some fields can be highlighted with syntax-highlighting
    and support so additionally the readability of the EDI file.

The native view displays the EDI file record-by-record:



If the standard presentation is not sufficient, individual layouts, including
CSV files, can be realized by individually, self-designed reports
.

Thus, a corresponding spreadsheet CSV representation is also available.



The file statistics displays information of the EDI file,
including the number of the individual segments:





1.2. Which messages are supported

Messages

DEENFR

ASCII

EBCDIC

UNICODE


Upgradeable


Layouts

EDIFACT
-D94A - D16B


(green star)

(tick)

(tick)

(minus)


(thumbs up)


-XXX_DELFOR_de_en
-XXX_INVOIC_de_en

-96A_INVRPT_en

IDOC
-DELFOR: 01 - 02
-DELVRY: 01 - 07
-DESADV: 01

-GSVERF: 01 - 03
-INVOIC: 01 - 02
-INVRPT: 01
-ORDERS: 01 - 05
-PEXR: 01 - 03
-PROACT: 01
-SHPMNT: 01 - 06

(green star)(green star)(green star)

(tick)

(minus)

(tick)


(thumbs up)


-DELFOR02_de
-ORDERS05_de

ODETTE
- Version 3
- ENGDAT: V1,V2


(green star)

(tick)

(tick)

(minus)





VDA
-4905=Lieferabruf
-4906=Rechnung
-4907=Zahlungsavis
-4908=Gutschrift
-4913=Lieferschein
-4915=Feinabruf
-4916=Prod.Synchr.Abruf
-4920=Speditionsauftrag
-4927=Ladungsträger

(green star)(green star)(green star)

(tick)

(tick)

(minus)




-4905_de
-4906_de

-4907_de
-4908_de
-4913_de
-4915_de
-4927_de

DIVFIX
- INTRASTAT_DE
- INTRASTAT_FR

(green star)
(green star)

(tick)

(minus)

(minus)





ANSI ASC X12
- 2003: 830


(green star)

(tick)

(tick)

(minus)


contact author
-002003_830_en
-004010_830_en

XML





(tick)

(minus)

(tick)





Other files 1:1
